Description
Key Points:
| MRC Rated Capacity | 3000 lb |
| Voltage | Battery Power 12 VDC |
| Wire Rope Included | Steel °3/16 in x 50 ft | °4.8mm x 15 m |
| Speed (f/m) / min | 6~23 ft / 1.9~7.1 m |
| Control Included | Wired Remote Control |
| Warranty | 1 Year |
Technical Specifications:
| MRC Rated Capacity | 3000 lb | FCC Cert ID | 2ASYP-DW12K |
| Number of Speeds | 1 Speed | Transmission / Reducer Type | 3-Stage Planetary |
| Voltage | Battery Power 12 VDC | Free Spooling Clutch Type | Cam Activated |
| Speed (f/m) / min | 6~23 ft / 1.9~7.1 m | Gear Ratio | 166:1 |
| Control Voltage | 12 V | Accessories | Control and Installation Hardware |
| Control Included | Wired Remote Control | IEC Motor Protection | IP67 |
| Motor Model | DC Permanent Magnet Motor | Warranty | 1 Year |
| Motor AMP | 230 AMP | Fairlead | Included |
| Drum Brake | Automatic | Number of Layers | 4 |
| Wire Rope Included | Steel °3/16 in x 50 ft | °4.8mm x 15 m | Drum DL Length | 74 mm |
| 1st Layer MRC Capacity | 3000 lbs | Drum BD Barrel Diameter | 50 mm |
