Description
Key Points:
| MRC Rated Capacity | 660 lb |
| Voltage | 1 Phase 110~120V 60Hz |
| Speed (f/m) / min | 36~49 ft / 11~15 m |
| Number of Speeds | 1 Speed |
| Control Included | Wired remote control |
Key Features:
- H2/M3/1Bm/Class A duty cycle classification applies to lifting equipment used in light manufacturing, service, and maintenance tasks in machinery workshops, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 2,500 hours
- Control System Powered By High PerformanceContactors with a powerful 1.1 KW Motor with IP55IEC Motor Protection
- Standards Compliance and or Certifications ASME B30.7 ,,
Technical Specifications:
| MRC Rated Capacity | 660 lb | 1st Layer MRC Capacity | 661 lb / 300 kg |
| Number of Speeds | 1 Speed | Transmission / Reducer Type | Planetary Reducer |
| Standard Lifting Height | 100 ft / 30 m | Free Spooling Clutch Type | NO |
| Voltage | 1 Phase 110~120V 60Hz | IEC Electric Enclosure Protection | IP65 |
| Speed (f/m) / min | 36~49 ft / 11~15 m | IEC Motor Protection | IP55 |
| Control Voltage | 110V | Standards Compliance | ASME B30.7 |
| Control Included | Wired remote control | Warranty | 1 Year |
| Motor Model | Electric AC | Drum DL Length | 124 mm |
| Motor Power | 1.1 KW | Drum FD Flange Diameter | °7 mm |
| Drum Brake | NO | Drum BD Barrel Diameter | °90 mm |
| Wire Rope Included | °7 x 98 ft / °7 x 30 m (drum cable capacity) |
