Description
Technical Specifications:
| Number of Speeds | 1 Speed | Transmission / Reducer Type | 3-Stage Planetary |
| Voltage | Battery Power 24 VDC | Free Spooling Clutch Type | Sliding Ring Gear |
| Speed (f/m) / min | 2~20 ft / 0.5~6 m | Gear Ratio | 150:1 |
| Control Voltage | 24 V | Electric Control Box | Reverse Solenoid Control Box |
| Control Included | Wireless and Wired | Accessories | Control and Installation Hardware |
| Motor Model | DC Series Wound Motor | IEC Motor Protection | IP67 |
| Motor AMP | 330 AMP | Warranty | 3 Year |
| Drum Brake | Automatic | Fairlead | Included |
| Wire Rope Included | Steel °21/64 in x 92 ft | °8.3 mm x 28 m | Number of Layers | 4 |
| 1st Layer MRC Capacity | 9500 lbs | Drum DL Length | 224 mm |
| FCC Cert ID | 2ASYP-DW12K | Drum BD Barrel Diameter | 64 mm |
